What is it?

The biomethane is a gas with the same chemical-physical properties of the Natural Gas (NG). Both are CH₄ rich gases (up to 99.0%). Differently from the NG which is recovered from non renewable fossil sources, the biomethane is recovered from the biogas which is produced from several renewable sources like agricultural products, zootechnical and agricultural wastes, FORSU and algae. The Biogas has a content of CH₄ in the range of 40-80% with the balance of CO₂. By the GM upgrading process the CO₂ is selectively removed from the Biogas producing the biomethane which can be utilized as a substitute of the NG.

Why choose GM

GM technology allows a total selective recovery of the methane and CO₂ contained in the biogas feed. The GM upgrading units are very flexible to treat biogas produced by difference sources. The ultimate goal is achieved by working closely with the client.
GM has a strong organization and structure to follow the client from the feasibility study to the plant management.

The advantages of our plant

Biogas Feed
Biogas compressor
Biomethane
CO₂ Gas
The plant
Skid

Hover over numbers
to discover
the advantages
of our plant

The process

How does it work?

The pretreated Biogas is compressed to about 8 bar (g) before entering a column for the selective absorption of CO₂ by backwashing with an aqueous solution of Br Carbonate
Potassium (K₂ CO₃). The Biogas, purified from CO₂, comes out as Biomethane from the head of the absorber at a pressure of about 8 bar (g). The residual CO₂ present in the Biomethane does not exceed 2% by volume, but it is possible to reach values of 0.5% if convenient. In fact, the non-condensable substances present in the Biogas

(such as for example O₂, N₂, H₂), remain mainly in the Biomethane. Biomethane, after cooling, drying and odorising, can be introduced into the Natural Gas (NG) network, which prescribes the maximum quantities of non-condensable products and compliance and possible correction of the Wobbe index. Therefore, having high purity Biomethane as guaranteed by GM, which supplies Biomethane with a CH₄ content, net of non-condensable substances, which can reach 99.5%, has a great cost benefit.

correction of the Wobbe index. Biomethane, alternatively, can be further compressed and used as a biofuel. The solution that has absorbed the CO₂ leaves the bottom of the absorber and enters a regeneration column at atmospheric pressure where the CO₂ is partly released thanks to the pressure jump and partly by stripping with steam produced by the same solution by means of an external heat source.

The CO₂ is recovered from the top of the regeneration column at high purity (>99.90% dry basis) and, after cooling, can be vented without further treatment or liquefied and re-utilized as raw material for multiple uses (like dry ice, soft drinks and other). The absorbing solution exiting the regeneration column free from the CO₂ is recycled to the absorption column. The methane present in the Biogas that powers the purification plant is almost entirely recovered; methane losses are less than 0.05%.

ENERGY CONSUMPTION

0,15 - 0,2 kWh/Nm³ of biogas

THERMAL ENERGY CONSUMED

0,10 - 0,15 kWh/Nm³ of biogas

CO₂ in the biomethane

<2%

RESIDUAL METHANE IN THE OFF-GAS.

0,06% (no post-treatement required)

METHANE CAPTURE

>99,95%

Process scheme

Biogas
- Pressure: any
- CO₂: 20 - 60%
- CH₄: 80 - 40%
- Other gases: as per grid injection regulations/fuel standards.
Dried biomethane
- Pressure: 8 bar(g)
- CO₂: < 2 %
- CH₄: balance
- Other gases: as per grid injection regulations/fuel standards.
- Other gases: -5°C@ 70bar(g)
Off-Gas
- Pressure: 0 bar(g)
- CO₂: 99,94%
- CH₄: 0,06%
- H₂S: as per grid injection regulations/fuel standards.

Our strength

Technology

GM has selected a simple and safe CO₂ removal process wide referenced in the world in several different applications. Simple because is utilizing well know and reliable equipments successfully proven in the industry since many years. Safe because free from utilisation of hazardous products and componentsThe up to date technologies and know-how are applied during the activities of designing, construction and operation of the unit.

Costs

The maintenance cost is reduced at the minimum thanks to the selection of top quality equipments and to the adoption of first class engineering standard. The operating cost is at the lowest range compared to the competitors technologies available on the market.

Efficiency

The efficiency, in term of amount of CH₄ recovered from the Biogas, is extremely high overcoming the 99.90%. The final purity of the biomethane from the upgrading unit is very high and, depending on the characteristics of the biogas, a CH₄ content of 98.0-99.0 is easily achieved.

Recovered CO₂

By implementing the optional CO₂ recovery unit supplied by GM, the totally of the CO₂ removed from the biogas is available at high purity for food industry like dry ice production, soft drinks and breweries or other industrial application like cryogenics uses and greenhouse or algae growing.

Comparing technologies

“Some say that the optimal biogas upgrade technology has yet to be discovered....”

We disagree.

CHEMICAL ABSORPTION
The solutions of Amines or K₂CO₃ utilised in Chemical Absorption are the most efficient and generate the purest Biomethane with high heating values.

Due to the low solubility of methane in the absorption solutions, the processes do not require any post- treatment of the Off-gas, as the loss of Biomethane in the process is negligible.

K₂CO₃ solution additionally is more stable (no degradation of the solution during the process) than an Amines solution and not dangerous to manipulate. K₂CO₃ also requires less regeneration heat and allows for a simpler more compact plant layout.

PHYSICAL ABSORPTION
Physical absorption uses either Pressurized Water Scrubbing (PWS) or organic solvents.

Water scrubbing when compared to chemical scrubbing absorbs less CO₂ and requires larger columns with greater liquid circulation.

The Methane recovery is also lower, as Methane partially dissolves in water, therefore the Off-gas requires post- treatment by thermal or catalytic oxidation before it can be released into the atmosphere.

MEMBRANE SEPARATION
Membrane separation exploits the different molecular size of each component of Biogas to separate each other by a semi- permeable membrane.

As the separation of the CO₂ from the raw Biogas is only partial through each pass, the scrubbing process requires several stages of membranes to achieve an acceptable separation, increasing investment and operating costs.

Membranes are very sensitive to impurities contained in the raw Biogas and periodical or emergency replacements are required during the normal operation.

PRESSURE SWING ADSORPTION
In Pressure Swing Adsorption (PSA) CO₂ is adsorbed in vessels filled with a molecular sieve made-up of activated carbon or zeolites.

The adsorption takes place at an elevated pressure while thesaturated vessels are regeneratedby cyclical depressurization.

The Off-gas however requires a post-treatment to oxidize the significant residual methanecontent prior to it being releasedto the atmosphere.

CONCLUSIONS:

The high CO₂ absorption rate and minimal Methane loss of an Amines chemical scrub solution.
The use of non-hazardous products in water washing.
The limited unit footprint of a Membrane Separation process.

Optional units

The base configuration of the GM upgrading unit can be expanded by adding optional units according to the clients or to the market requirements.

Removal of contaminants from the biogas

The biogas from the anaerobic digestion can be contamined by differents impurities like hydrogen sulfhide (H₂S), ammonia (NH₃) and siloxanes (R₂SiO)n, depending on the quality of the feed to the digesters and on the applied digestion technology.GM can offer suitable technologies for the removal of the contaminants in order to meet the following targets:ul>

Reliable operation of the GM upgrading unit;

iBiomethane specification according to the required standards;

Food grade for the recovered CO₂ (if required);

Gases emission according to the local regulations;

Drying of the biomethane

The biomethane from the GM upgrading unit is saturated by water at about 10°C.GM can offer a suitable drying unit to achieve the biomethane dew point required by the final users standards.

Heat recovery

As the hot off-gas (CO₂ + H₂O) from the CO₂ stripping column shall be to some extent cooled, the available heat can be advantageously recovered for other services like an integration to the heating for the anaerobic digestion or to the building heating system.GM can offer a package heat recovery unit customized according to the clients requirements.

Recovery of the CO₂

The high purity CO₂ from the stripping column of the GM upgrading unit, instead to be vented as normally is done with the upgrading competitors processes, can be liquified and sold in the market at food grade quality.
GM can offer a package CO₂ recovery unit customized according to the clients requirements.
